The 12-Volt 12mm Regulated Pixels from Mattos Designs feature the WS2811 integrated circuit for precise color control. Manufactured with white Printed Circuit Boards (PCBs) created by routers, these units eliminate manual cutting risks. They are compatible with standard 12V DC power supplies and available as either 12mm Bullet Pixels or 12mm Square Nodes.
Key Specifications
-
Voltage: 12V DC
-
Protection: IP68 Rated Waterproof coating with Fire-Resistant Epoxy
-
Pigtail: Options include 4 inches or 1M spacing
-
Wire: 0.323 sq mm black wire; negative pole marked by a white dashed line
-
Certification: CE, RoHS, and FCC compliant
Installation requires careful attention to polarity markings found on the lead pigtail. Modifications, cuts, or alterations void the coverage. A limited two-year warranty applies from the purchase date for non-defective usage. To service the product, submit a video demonstration paired with a description of the issue. This process ensures accurate troubleshooting for outdoor lighting maintenance.
