12V Low voltage Pixels P12A (LB1908)

12V Low Voltage Pixels P12A (LB1908) RGB Pixel Light

P12A delivers compact, low-power RGB pixel lighting with rugged protection and strong grayscale performance. Designed for starlight decorative effects, eye-catching signage fonts, and subtle backlighting, it provides vibrant color rendering while keeping power usage minimal. It supports TTL control for straightforward integration with standard LED drivers, and can drive large arrays without extra power injection.

Models and electrical specifications

• P12A-RGB-TTL-12 — DC12V, rated power 0.5 W, TTL control
• P12A-RGB-TTL-5 — DC5V, rated power 0.3 W, TTL control

Key features

• LED chipset: LB1908
• LED beam angle: >120 degrees
• IP rating: IP67 for durable outdoor and harsh-environment use
• Shell color: transparent
• UL Listed model: P12A
• Storage temperature: -40 to 75°C
• Operating life: ≥ 30,000 hours
• Installation method: perforated or wound
• Connect up to 300 pixels at 100% brightness with no power injection
• Control mode: TTL

Why choose P12A

With a focus on reliability and versatility, P12A combines low power draw with high protection and precise color control. Its RGB capability and TTL compatibility simplify complex lightingSchemes for signage, decorative installations, and backlighting projects, while the IP67 rating ensures resilience against dust and water exposure. The transparent shell maintains a clean, unobtrusive appearance in finished installations.

Use cases

• Starlight-style decorative features in architectural or landscape installations
• Dynamic advertising fonts and banners with rich RGB color
• Backlighting for displays, panels, or channel letters
