12v Low voltage Pixels P24B (Gumdrop)

12v Low Voltage Pixels P24B (Gumdrop)

P24B is a compact, low-power point light source designed to bring precision and versatility to starlight decorations, advertising fonts, backlighting, and a variety of scene applications. This UL Listed, low-voltage pixel module is built for reliable performance with TTL control support, enabling smooth, scalable color and brightness transitions across RGB configurations.

• EZ Push- Quick Installs
• Rated power: 0.15 W at 12 V DC
• Control mode: TTL
• RGB compatibility with TTL addressing (P24-RGB-TTL)
• Luminous flux: 2.99 lm
• LED efficacy: 19.9 lm/W
• Beam angle: > 120 degrees
• Lead wire specification: 3 × 0.3 mm²
• Electrical rating: Class III
• IP rating: IP67 (water and dust resistant)
• Flammability rating: 94-V0
• Operating life: ≥ 30,000 hours
• Applications: starlight decoration, advertising fonts, backlight and other scene applications

Why P24B stands out

Designed for durability and ease of integration, P24B combines ultra-low power consumption with robust protection and broad light distribution. The IP67 rating means dependable outdoor and damp-environment performance, while TTL control provides precise, scalable color and brightness for dynamic displays. With a long operational life and a compact footprint, it’s an efficient choice for creating vivid, eye-catching visuals without overburdening your power and wiring.

Key specifications at a glance

• Model: P24B (RGB TTL variant available under P24-RGB-TTL)
• Rated power: 0.15 W
• Rated working voltage: DC 12 V
• Control mode: TTL
• Luminous flux: 2.99 lm
• LED efficacy: 19.9 lm/W
• Beam: > 120 degrees
• Lead wire: 3 × 0.3 mm²
• Electrical rating: Class III
• IP rating: IP67
• Flammability: 94-V0
• Operating life: ≥ 30,000 hours
