The Mattos Designs EVO 12mm Pixels integrate a native 12-volt WS2811 chip with the LED package, eliminating additional support components and optimizing reliability. Operating at 8mA per pixel, these units consume significantly less energy than alternative designs, enabling higher pixel densities before voltage drop requires manual power injection.
An epoxy-coated board and wire assembly over-molded into a protective PVC shell achieves an IP67 waterproof rating. The tapered 12mm casing mounts flush against 10mm coroplast props using secure locking nubs. Surface markings identify data terminals, streamlining wiring for complex displays.
-
Voltage: 12V DC
-
Protocol: WS2811 compliant
-
Spacing: 2.25-inch or 4-inch intervals
-
Wire: 10-strand black wire standard
-
Safety: UL Listed package; CE, RoHS, FCC certifications
Strings are available in varying lengths from 25 to 200 pixels. Using 1,000 pixels reduces prop weight by 11.25 lbs compared to traditional 12V bullet systems. Unmodified and uncut pixel strings include a 3-year warranty.
