The EVO Dynamic Energy Amplifier by Mattos Designs provides dedicated power injection capabilities for managing pixel strings in holiday lighting displays. This electronic module maintains signal integrity and voltage levels along extended wire runs by delivering 100W of boosted power. The amplifier is available in configurations for direct current voltage standards of 5V, 12V, or 24V.
Integrated data boosting circuitry refreshes incoming control signals to prevent dimming or flickering in distant sections of the display layout. Operational safety involves an internal poly fuse that automatically resets after power cycling when current anomalies are detected. The protective housing carries an IP67 waterproof rating suitable for permanent or temporary exterior seasonal setups.
-
Operating Voltages: Configured for 5V, 12V, or 24V DC
-
Maximum Output: 100 Watts continuous across models
-
Interface Connectors: Inlet and outlet utilize waterproof xConnect pigtail style
-
Power Source: Equipped with a standard 3-prong AC cord
Installing this amplifier at intermediate junction points prevents power loss where long runs connect to controllers. This configuration ensures uniform illumination across architectural lighting applications without requiring external transformers at multiple endpoints.
