The EVO Mag Mount Pixel features an integrated plastic mounting body with a pre-applied magnet for adjustable deployment. These 12V LEDs use a native voltage architecture requiring no additional resistors or regulators. Each unit maintains a fixed 4-inch center-to-center spacing, permitting uniform distribution across signage or architectural structures. The design prioritizes concealment during permanent installation.
Data redundancy ensures a single pixel failure does not disrupt the entire string, supported by a signal reshaping circuit for transmission at 800 kbps. Operation occurs between 10.8v and 13.2vdc using the WS2811 protocol with standard 3248 RGB B LED chipsets. Environmental sealing involves an IP67-rated build with fully encapsulated PCBs and wires contained within a protective PVC shell.
Technical Specifications
-
Power Requirements: 12V DC Native (Operating Range: 10.8v - 13.2vdc)
-
Current Draw: 9mA @ 12v
-
Light Output: R 100-300 mcd, G 200-600 mcd, B 50-200 mcd
-
Temperature Rating: -40°C to +85°C (-40°F to 185°F)
-
Included Hardware: 100-pixel pack with four 4-to-3 Adapter xConnect Pigtails
Constant current design reduces internal power draw and failure points. Units carry UL, CE, RoHs, and FCC certifications plus a 3-year warranty for unmodified products.
