The EVO Mini Pixels by Mattos Designs deliver high-density illumination in a compact 5mm diameter body, ideal for intricate props and signage. Native 12V technology reduces power draw, drawing only 9mA at 12V. Each unit operates efficiently across a voltage range of 10.8V to 13.2V DC without requiring on-board resistors.
With mcd values reaching up to G 600, these lights rival traditional bullet pixels yet remain lightweight at 238 grams per 100 pixels spaced 4 inches apart. The entire assembly is encapsulated in PVC, providing an IP67 waterproof rating in temperatures from -40°C to +85°C. A stackable overlapping base enables secure insertion into materials like 10mm coroplast. Units include marked +Data- lines and built-in signal reshaping circuits supporting 800kbps data transmission via 20-gauge black wire and 3-wire xConnect pigtails.
Certified UL Listed, CE, RoHS, and FCC compliant, these WS2811 protocol LEDs feature a three-year warranty for unmodified strings. Purchase options include 25, 50 or 100-count packages suitable for various lighting project needs and inventory planning.
