The Mattos Designs EVO Permanent Mount Pixels provide durable 12V LED lighting for permanent exterior and interior architectural displays. Integrated 3M VBH adhesive pads allow for fixed placement without external brackets, while the 4-inch center-to-center spacing facilitates discreet mounting.
Built with a 3248 RGB chipset, each pixel operates efficiently within a 10.8V to 13.2V DC range. Every unit draws 9mA of current and connects via 4-wire xConnect pigtails secured with standard 20-gauge black wire. A 4-pin to 3-pin input adapter is included for controller compatibility. An internal signal reshaping circuit maintains data transmission at 800kbps across longer runs. Redundant data architecture ensures individual pixel malfunctions do not propagate errors down the string.
Physical protection is rated IP67, featuring encapsulated PCBs and wires encased in a PVC shell. The operational temperature span covers -40°C to +85°C (-40°F to 185°F), supporting year-round usage. Units carry UL Listed, CE, RoHS, and FCC certifications. Packages contain 100 units and include a 3-year warranty for uncut and unmodified strings.
