The Phoenix Ray Pro 600W Moving Head Light is engineered for precision in professional stage and outdoor applications. Utilizing an original customized Osram lamp, this fixture emits a luminous flux of 660,000 lumens at 10 meters per the manufacturer specifications, with a projected lifespan between 1,500 and 2,000 hours.
To facilitate diverse visual outputs, the light incorporates a color wheel featuring 11 colors plus white, supporting half-color and rainbow effects. Patterns are managed by an advanced gobo wheel with 14 fixed designs and bidirectional shaking, paired with an 8-facet prism allowing bidirectional rotation. Users can adjust the beam angle between 0 and 1.2 degrees for targeted projection. The unit operates wirelessly via built-in receivers compatible with DMX512 and RDM protocols.
Constructed for durability, the housing utilizes high-hardness aluminum and flame-retardant PVC treated for UV resistance. The IP65 ingress protection rating ensures reliability during exposure to rain and dust, making it appropriate for festivals and outdoor productions. Setup is streamlined through an intuitive LCD display that supports programmable lighting scenes and auto-reset functions.
| Feature |
Details |
| Light Source |
Original Customized Osram Lamp |
| Luminous Flux |
660,000 lumens at 10 meters |
| Lifespan |
1,500 to 2,000 hours |
| Color Wheel |
11 colors + white, half-color, rainbow effects |
| Gobos |
14 fixed gobos + bidirectional shaking |
| Prism |
8-facet prism (3-facet, 16-facet optional) |
| Beam Angle |
0-1.2 degrees |
| Ingress Protection |
IP65 |
| Control Protocol |
DMX512 and RDM |
| Build Material |
High-hardness aluminum, flame-retardant PVC |
